Chemists beware - the metamaterialists are making startling progress.

Chemists beware - the metamaterialists are making startling progress. The latest structure composed of a metamaterial is a remarkable cloaking device that can render an object invisible to microwave radiation - in two dimensions at least.

Metamaterials are artificial structures that have unique electromagnetic properties. Engineering these properties into a material has traditionally been the preserve of the chemist by subtle manipulation of atoms and molecules. In metamaterials the desired properties are achieved by the precise geometrical arrangement of the components of the structure. When these components - small metal elements, for example - are significantly smaller than the wavelength of the impinging electromagnetic radiation, the metamaterial can be given electromagnetic properties that would be otherwise impossible to achieve.

The latest device has been designed by researchers from Duke University in North Carolina, US, together with John Pendry at Imperial College London, UK. Pendry had earlier provided the theory to create a system that would make an object invisible to microwaves.

The ’invisibility cloak’ consists of a series of concentric rings of a fibreglass-based composite upon which have been imprinted numerous U-shaped copper elements of millimetre dimensions in a precise geometric formation. The dimensions of these copper elements vary slightly on each successive concentric ring. The target object - a copper cylinder - sits in the centre of the innermost ring.


The invisibility cloak: a series of concentric fibreglass rings imprinted with U-shaped copper elements

As microwave radiation, of wavelength around 3 cm, strikes the cloak, the beams are diverted around the object and meet up at the other side - similar to the way that water flows around a boulder in a river.

The effect is achieved because of a subtle gradient in the electromagnetic properties of the cloak. ’The cloak’s material properties vary from point to point and vary in a very specific way,’ David Smith, one of the Duke researchers, told Chemistry World. ’When the phase fronts meet the material, they are swept smoothly around it due to the spatial distribution of the properties of the cloak.’

Pendry said, ’We knew that no naturally occurring materials would do the job, but the new class of metamaterials, which owe their properties to their internal structure rather than their chemistry, have proved yet again that they can meet some of the most extreme challenges.’

Or, as Smith jokingly said of chemists, ’We are your competition!’

Simon Hadlington
