Wastewater purification combines with fuel generation

Scientists in China have developed a new catalyst, composed of highly porous nickel molybdenum oxide nanorods, that can catalyse the urea oxidation reaction more efficiently than any previously reported non-noble metal catalyst. This discovery could offer a more cost-effective and energy-efficient route for hydrogen production.

Photo–electrochemical water splitting is seen as one of the most important reactions for sustainable fuel generation. Water splitting generally combines the oxygen evolution reaction and the hydrogen evolution reaction. Despite the significant advances already made, progress has stalled due to the sluggish kinetics of the oxygen evolution reaction. One potential solution is to replace conventional water electrolysis with the more energetically favourable urea electrolysis. ‘The thermodynamic potential of the urea oxidation reaction is a mere 0.37V, which is much lower than that of 1.23V for the oxygen evolution reaction, enabling an energy-saving hydrogen production technique,’ explains Shu-Hong Yu from the University of Science and Technology of China, who led the research.

Schematic illustration of the preparation of NF/NiMoO-Ar as a UOR catalyst and NF/NiMoO-H2 as a HER catalyst

Source: © Royal Society of Chemistry

Nickel molybdenum oxide compound found to have exceptional cathodic/anodic catalytic performance for urea electrolysis

In this study, the group have developed nickel molybdenum oxide catalysts for urea electrolysis with the highest efficiency reported so far. ‘We note that the urea oxidation reaction activity of our catalysts is superior to noble metal electrocatalysts, such as Pt/C and RuO2,’ says Yu. Electrocatalytic activity is sensitive to the valence state and coordination environment of metal centres. Yu’s new catalysts possess high oxidation states – Ni2+ and Mo6+ – which act as active sites and lead to increased activity. In addition, the catalyst’s highly porous structure results in a large surface area with many exposed active sites.

Mark Symes, an expert in electrocatalytic water splitting at the University of Glasgow, UK, remarks, ‘if you have porous materials, you can pack a lot of real surface area into quite a small space and this can give you good catalytic performance.’ However, he cautions that, ‘the results look promising but the researchers need to provide more insight into why the activity is so good.’

When compared to water electrolysis, urea electrolysis can significantly reduce the energy requirements. However, this process will consume the urea. Therefore, Yu proposes that ‘for practical applications, using urea-rich wastewater as the urea source is a good choice; this allows for the simultaneous production of hydrogen and wastewater purification.’ Symes remains unsure of the cost-effectiveness of this technique compared to standard water splitting. ‘Is the expense of obtaining the urea greater than just using water, which requires a little more energy to do the reaction?’ However, he does agree that, ‘if you do have a source of waste urea, you can get rid of this and make a saving on the energy so it is win–win.’
